FEATURES:

• 2 Channel Bass Restoration Processor:

  • Complete Tuning Control (Effect, Width, Frequency)

  • Variable Subsonic Filter

• Line Driver or Line Output Converter

• Includes Multi-Function Remote Level Control (RLC)

• Differential Balanced Inputs

• Low Impedance Outputs

• Variable Gain with Clip LED

• Auto Turn-On via DC-Offset or Audio Signal Detect

• Generated +12V Remote Output

• OEM Load Detect Compatible

• Selectable Ground Isolation

• Professional Grade Panel Mount RCA's

• Locking Detachable Power and Speaker Terminals

• Compact Aluminum Chassis w/Detachable Mounting Tabs

• LinkLD is required when integrating into all amplified (and most non-amplified) Chrysler / Dodge / Fiat / Ferrari / Maserati systems

SPECIFICATIONS:

• Output Voltage Max (RCA): >10V RMS

• Output Impedance: <50 Ohms

• Input Sensitivity (SPK/RCA): 2-20Vrms / 0.5-5Vrms

• Max Input Voltage (SPK): 40Vrms

• Frequency Response: 5-400Hz

• THD+N (SPK/RCA): <0.1% / <0.1%

• S/N (SPK/RCA): >118dBA / >128dBA

• Parametric (Boost/Q/Freq): 0 to +12dB / 1.5-5 / 30-80HZ

• Subsonic Filter: 5Hz-40Hz, -24dB/Oct

• Turn-On Trigger: +12V, DC-offset & Audio Detect

• Generated +12V Output: >500mA
